TRUMPF TruLaser 1040
Laser cutting services in Upstate SC
SDS’s fabrication shop features a TRUMPF TruLaser 1040 laser cutter capable of delivering precise, high-quality cuts in record time.
- 12-kilowatt solid-state fiber laser
- Cuts through material up to 1.57″ thick
- PierceLine technology for rapid, precise hole-punching
- CoolLine processing to prevent heat buildup while cutting
- Touchpoint control interface and built-in automation features for multi-run, repeatable cuts
Specs and Features
| Model Name | TRUMPF TruLaser 1040 12KW 6′ x 13′ |
| Laser Type | Solid-State Fiber (Wavelength: 1080 nm) |
| Laser Power | 12,000 Watts |
| Bed Size | 4,000mm x 2,000mm (~13.1′ x 6.6′) |
| Travel Speed | Up to 5,512 in/min. |
| Gas Types | Oxygen (O2), Nitrogen (N2), O2/N2 Blend |
| Compatible Materials | Mild Steel, Stainless Steel, Galvanized Steel, Aluminum, Copper, Brass |
Material Data
| Material | Maximum Cuttable Thickness |
|---|---|
| Stainless Steel | 1.57″ (40 mm) |
| Mild Steel | 1.25″ (32 mm) |
| Galvanized Steel | 1.25″ (32 mm) |
| Aluminum | 1.25″ (32 mm) |
| Copper | 0.5″ (12.7 mm) |
| Brass | 0.5″ (12.7 mm) |
